BC: dimension AM 1410mm, OHF: dimension FL 1744mm, connection 82x82mm, WITHOUT wheel brake, swing arm position 3°, axle profile 92mm. Read more...

Wishlist: Add to comparison:

Part no. OLD 45.37.000.018
Part no. NEW 4012097

Dimension FL
1744mm
Dimension SP
1860mm
Dimension AM
1410mm
Dimension L
1561mm
Offset (ET) 68mm
Model Fiat Ducato
Axle type DB2100
Axle load single axle 2100kg
Axle load: Tandem axel - - -
Wheel brake WITHOUT wheel brake
Suspension Square rubber suspension
RONDO arm 200mm
Connection 82x82mm



SCOPE OF DELIVERY
Axle WITHOUT wheel brake

DETAILS

  • Speed up to 140 km/h
... ...
