Home / CHASSIS PARTS / CHASSIS PARTS AL-KO / AXLES / BRAKED AXLES & ACCESSORIES / BRAKED AXLE 900 - 2000KG DELTA, AXLE TYPE SI-N, AXLES FOR CARAVANS / Bowden cable 05.089.51.49.0 hook in with thread M10
sheath length (L) 1400mm, cable length (L1) 1660mm, can be used with wheel brake S3006-7, bell internal diam. 25.5mm, outside 30mm. Read more...
| X = part no. OLD / NEW |
05.089.51.49.0 / 4017351 |
| L = sheath length |
1400mm |
| L1 = cable length | 1660mm |
| D1 |
M10 |
| D2 | 25.5mm |
| can be used with wheel brake | S 3006-7 |
SCOPE OF DELIVERY
1 Bowden cable
Per axle, please order: 2 units
Here, you can find the catalogue page as a convenient PDF download.
