BC: dimension A 1340mm, OHF: dimension C 1822mm, wheel connection 112x5, wheel brake type 1637, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm.
BC: dimension A 930mm, OHF: dimension C 1380mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm, ball-head wheel bolts M12x1.5.
BC: dimension A 1445mm, OHF: dimension C 1890mm, wheel connection 98x4, wheel brake type 1637, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm.
BC: dimension A 1230mm, OHF: dimension C 1700mm, wheel connection 100x4, wheel brake type 2051 A, offset (ET) 27-33mm, swing arm position 25°, axle profile 80mm, taper-head wheel bolts M12x1.5.
BC: dimension A 1020mm, OHF: dimension C 1470mm, wheel connection 100x4, wheel brake type 2051 A, offset (ET) 27-33mm, swing arm position 25°, axle profile 97mm.
